Atoll CD80 EVO

The Evolution series CD players benefit from numerous innovations in terms of power supplies or audio and conversion stages. In addition, all these devices can now receive a 24 bits/192 kHz DAC board based on the player’s internal converter. The USB input is asynchronous.

4 mm brushed aluminium front panel.
10 regulated power supplies, including a specific low-noise one for the converter.
Linear power supply for digital stages with a specific 30 VA transformer.
Separate 4,6 VA linear transformer for audio stages.
1,6 VA transformer (low consumption).
Original TEAC central CD mechanics (latest generation).
Pure audio CD player compatible with: CD, CD-R, CD-RW, MP3, WMA-AAC.
Double-sided circuit boards with nickel/gold finish.
BURR-BROWN PCM1791A converter:
– 24-bit/192 kHz.
– Dynamic range: 113 dB.
– Signal-to-noise ratio: 113 dB.
Low-power OLED display.
CD-Text display.
Differential audio output stages with discrete components biased in class A.
ATOLL global remote control.
Optional 24 bits/192 kHz digital card for all Evolution series CD players.

TECHNICAL DATA:

Supply: 30 + 4.6 + 1.6 VA
Total of capacitors: 21,400 µF
Converter (D/A): PCM1791A
Dynamic: 113 dB
Signal/Noise Ratio: 113 dB
Distortion at 1 kHz: 0.001%
Output level: 2.5 Vrms
Output impedance: 5.6 Ω
Bandwidth: 5 Hz – 20 kHz
Rise time: 2.0 µs
Standby consumption: < 0.5 W
Operating consumption: 9 to 16 W
Dimensions (mm): 440×280×95
Weight: 6 Kg
