Atoll MD100 EVO

The latest addition to the Mini line, the MD100 Evolution player is the ideal complement to our “Mini-system” elements for playing your CDs. This player benefits from quality components, particularly a TEAC CD reading mechanism compatible with CDs, CD-R, CD-RW, MP3 files, and WMA-AAC.

4 mm brushed aluminium front.
Low consumption 10 VA transformer.
7-segment LED display.
BURR-BROWN PCM5122 converter:
– 24 bits/192 kHz.
– Dynamic: 112 dB.
– Signal/Noise ratio: 112 dB.
Double-sided circuit boards with nickel/gold finish.
Original TEAC central CD mechanism (latest generation).
Pure audio CD player compatible: CD, CD-R, CD-RW, MP3, WMA-AAC.
Separate regulated power supply for audio stages.
Ability to manage display intensity.
ATOLL global remote control.

TECHNICAL DATA:

Power supply: 10 VA
Total of capacitors: 11 094 µF
D/A converter: PCM5122
Dynamic: 112 dB
Signal/Noise ratio: 112 dB
Distortion at 1 kHz: 0,002%
Output level: 2,0 Vrms
Bandwidth: 5 Hz – 20 kHz
Rise time: 2,0 µs
Standby consumption: < 0.5 W
Operating consumption: 2 to 4 W
Dimensions: 320×210×83 mm
Weight: 2,4 Kg
