Atoll SDA200 SIGNATURE Zwart

STREAMER / DAC / INTEGRATED AMPLIFIER.
Whether it’s listening to music in high-definition streaming, locally from your network, from a USB key, from a hard drive, via Bluetooth®, or your favourite internet radios, our “All-in-one-un” SDA200 Signature is fully adapted to current needs related to the playback of dematerialised music files. In addition, it has very complete connectivity. Finally, the SDA200 Signature integrates a high-performance converter and the amplifier part of the IN200 Signature.

8 mm brushed aluminium front.
2 toroidal transformers of 340 VA each.
Total of capacitors: 65 800 µF.
2×120Wrms / 8Ω.
MOS-FET dual push-pull power stage.
High-quality, shielded MKP technology link capacitors.
Filtering capacitors: 8×6800 μF high quality, low ESR specific for ATOLL.
BURR-BROWN PCM1792 converter:
– Dynamic: 129 dB.
– Signal/Noise ratio: 129 dB.
5″ TFT LED colour graphic display (800*480).
Discrete component preamp stages without negative feedback in pure Class A.
Analog volume management (switched resistors) that can be bypassed.
A specific power supply is dedicated to the audio stages.
A particular power supply is dedicated to the analogue digital audio converter.
Accepted resolutions: PCM up to 24 bits/192 kHz and DSD64 and DSD128.
Playback of audio files present on the network (DLNA and UPnP compatible) in a wired RJ45 or WiFi connection.
Display of names, tags, resolutions and album covers.
“Gapless” system (no cut between pieces).
Ability to create playlists.
USB-A file systems: FAT32, NTFS, EXT2/3/4.
ATOLL “streamer” remote control supplied as standard.
“ATOLL Signature 2” App (Android and IOS).

CONNECTIVITY

Inputs
2 Analog inputs – 2 coaxial S/PDIF (PCM1792 24 bits/192 kHz).
2 Toslink optical S/PDIF inputs (24 bits/192 kHz PCM).
2 USB-A inputs (1 front and 1 rear).

1 RJ45 network socket.
1 Bluetooth® receiver (antenna).

Outputs
Speakers.
1 Pre-out output.
1 Coaxial S/PDIF output.
1 Toslink optical S/PDIF output.

1 Trigger output 12V.
1 Headphone output on the front panel (Ø 6,35 mm – 1/4″).
1 Wi-Fi antenna (802.11b/g/n).

TECHNICAL DATA

Power supply: 689 VA
Wrms/channel/8Ω: 2×120 W
Wrms/channel/4Ω: 2×200 W
Total of capacitors: 65,800 μF
Dynamic: 129 dB
Input impedance: 220 kΩ
Maximum input level: 3,5 Vrms
Distortion at 1 kHz: 0,05% / 10 W
Bandwidth: 5 Hz – 100 kHz
Rising time: 2.0 μs
Sensitivity: 350mV
Signal/Noise Ratio: 129 dB
D/A converter: BURR-BROWN PCM1792 24-bit/192 kHz
Dimensions: 440×365×95 mm
Weight: 13 kg
